Milk-V Mars RISC-V Single Board Computer Startfive JH7110 (4GB RAM,Basic Kit)

Shipping List Only Board : 1 x Milk-V Mars SBC Basic Kit: 1 x Milk-V Mars SBC, 1x5V3A Power with cable Developer Kit: 1 x Milk-V Mars SBC, 1x 32GB TF Card, 1x5V3A Power with cable, 1x TTL2USB Debug , Suppot: Click "Kocoo" to ask. Tech Specs Milk-V Mars is a high-performance RISC-V Single Board Computer (SBC) the size of a credit card, built on the StarFive JH7110. This four-core device supports a plug-and-play eMMC module, as well as up to 8GB of LPDDR4 memory. The board is equipped with three USB 3.0 ports, one USB 2.0 port, an HDMI 2.0 port that supports 4K resolution, an RJ45 Ethernet port that supports PoE (Power over Ethernet), and an M.2 E-Key slot for a WIFI/BT module. It also includes a 4-lane MIPI CSI and a 2-lane MIPI CSI, along with a 40-pin GPIO. Hardware SoC StarFive JH7110 64bit SoC with RV64GC, up to 1.5GHz Memory up to 8GB LPDDR4 Storage 1x eMMC Slot 1x Micro SD Slot 1x SPI Flash for bootloader Video output 1x HDMI 1x mipi DSI(2-lane) 1x mipi DSI(4-lane) Max dual display output: 1 HDMI + 1 MIPI DSI Multimedia Camera with MIPI CSI(2-lane) H.264 & H.265 4K@60fps Decoding H.265 1080p@30fps Encoding JPEG encoder/decoder Connectivity 1x RJ45 Gigabit Ethernet 3x USB3 + 1x USB2 1x M.2 E-Key Power USB-C port 5V DC (minimum 3A+) GPIO Power in, 5V DC via GPIO header (minimum 3A+) PoE with add-on PoE HAT GPIO 40 Pin GPIO Header Dimensions 85mm x 56mm Button 1x Recovery botton Other 2 Pin 5V slot for FAN

• Milk-V Mars is a high-performance RISC-V Single Board Computer (SBC) the size of a credit card, built on the StarFive JH7110. Up to 8GB LPDDR4 RAM.SoC StarFive JH7110, 64bit SoC with RV64GC, up to 1.5GHz
• This RISC-V Single Board Computer provides 3 boot options through which you can expand more storage space.1x eMMC Slot ,1x Micro SD Slot , 1x SPI Flash for bootloader
• Complete online documentation is provided to make it easy for you to use it and open the door to risc-v. check: http(s:)//milkv.io/docs/mars/overview
• Milk-V Mars is similar to the Raspberry Pi version, it has USB3.0 x3 , USB2.0 X1 a total of 4 USB ports. It has HDMI 2.0 with up to 4K support and an RJ45 Gigabit Ethernet port.
• This RISC-V SBC compatible with Raspberry Pi 40PIN GPIO, and support POE function through POE expansion board.
